| SDD5 diesel locomotive is used for main line freight transportation on broad gauge railway. The locomotive consists of two identical cars A and B, which are in fixed multiple connection. The whole locomotive can be controlled uniformly in the cab of any one car. The locomotive is equipped with 16V240ZJD diesel engines, with service power of 3240kW and maximum running speed of 100km/h. The locomotive is equipped with microcomputer control system and running safety speed monitoring system. |
Main Technical Parameters |
| Application | Main line freight transportation | Track Gauge | 1520mm |
| Axle Arrangement | (C0-C0)+(C0-C0) | Wheel Diameter | 1050mm |
| Axle Load | 23t | Locomotive Service Weight | 2×138t |
| Max. Service Output of Diesel Engine | 880kW | Min. Negotiable Curve Radius | 125m |
| Max. Running Speed | 100km/h | Continuous Speed | 23.6km/h |
| Max. Starting Tractive Effort | 2×442kN | Continuous Tractive Effort | 2×340kN |
| Fuel Capacity | 2×9000L | Oil Capacity | 2×1200kg |
| Sand Capacity | 2×800kg | Overall Dimensions (L×W×H) | 22240mm×3337mm×4736mm (single loco.) |
